p r o d u c t s

COPEX premieres REFLEX shears

Automatic flat-screen disassembly

TSC releases non-ferrous ‘Rascal’

French manufacturer COPEX has
unveiled a range of mobile scrap
shears bearing the name REFLEX.
These have been developed for
compacting and shearing weld-
ed structures, white goods, car
bodies, collected scrap and all
kinds of non-ferrous metals.
The REFLEX series comprises three mod-
els, all of which are said to be ‘ideal’ tools
to process scrap materials both rapidly
and economically. Equipped with an
‘extremely efficient’ shear with a cutting
force of either 500 tonnes, 650 tonnes
or 900 tonnes, the new COPEX equip-
ment is claimed to produce high-quality
bales. An innovative slide guiding system
is integrated into the design for high cut-

Swedish recycling technology
expert MRT System International
has expanded its portfolio with
the launch of the Flat Panel Pro-
cessor FPP60. The new tool will
help recycle up to 60 flat panel
screens per hour, it is claimed.
‘The production result yields fractions
such as plastic films, metals and printed
circuit boards of very high quality, with

German recycling technology
specialist Vecoplan has devel-
oped a high-performance, heavy-
duty re-shredder known as the
VEZ 2500 which, it is claimed, is
best suited to the generation of
refuse-derived fuel out of pro-
duction and sorting residues.
The VEZ 2500 is a compact, single-shaft
unit for shredding of pre-shredded fer-
rous/non-ferrous and air-classified recy-
clables. It also retrieves the high calorific
fraction from domestic and municipal
solid waste, explains Vecoplan.
The shredding unit consists of a large
cylindrical solid steel rotor and two solid
counter knives. The latter deliver a ‘very
homogeneous output particle structure’

US manufacturer TSC has
announced the launch of its Por-
table 6060 Little Rascal Top and
Bottom Discharge (TBD) Shred-
der System.
Equipped with a feed system with
40-degree feed ramp, the TBD is her-
alded as a modern-day ferrous separa-
tion solution. It features a tilt table,
single feed roll with hydraulic drive,
four completely portable trailers as well

ting performance and reduction of main-
tenance costs by roughly a third, accord-
ing to the manufacturer. The ‘balanced
distribution’ of cutting efforts consider-
ably increases the reliability of the shear
frame, it adds.
In developing the REFLEX range, the
company’s aim was ‘combining mobility
and robustness’, it notes. Besides mobile
configurations with three, four or six
axles, semi-mobile shears are also avail-
able.

COPEX, France,
Phone: +33 (0)297 7626 44,
Fax: +33 (0)297 7634 12,
Email: sav.copex.com
www.copex.com

a minimum of manual labour involved,’
states MRT. A major advantage of the
FPP60 is that it can replace ‘the greater
part’ of the manual disassembly required
for this type of product.
In the process, integrated saw blades cut
open the flat panel to enable further
disassembly of the unit, with safe isola-
tion of the integrated and mercury-con-
taining fluorescent lamps. MRT’s FPP 60
is ventilated and comes with a ‘top-of-
the-line ventilation system’ to improve
the safety and reliability of the process.

MRT, Karlskrona, Sweden,
Phone: + 46 455 30 28 70,
Fax: + 46 455 30 28 79,
Email: [email protected]
www.mrtsystem.com

thanks to the doubled number of cuts
per rotation. The machine also includes
rotor tooth cutters in the form of
V-shaped ‘hardened single cut-
ters’, as well as counter knives
consisting of six individual
segments. Heat-up is reduced
owing to the very small cut-
ting gap, thus saving energy
and maximising throughput capacity.
The VEZ 2500 comes with the HiTorc-
drive unit and the speed-controllable
and almost silent HiTorc motor.

Vecoplan, Westerwald, Germany,
Phone: +49 2661 6267 174,
Fax: +49 2661 6267 70,
www.vecoplan.de

as TSC’s proven PLC Smart Shredder
System.
The new TDB model has shredder drives
of 500 HP (10 tonnes per hour) or 2000
HP (60 tonnes per hour).

TSC, Canutillo, USA,
Phone: +1 915 877 3814,
Fax: +1 915 877 5199,
Email: [email protected]
www.theshredderco.com Vecoplan unveils RDF re-shredder
